Most factories need an ETP; only some need ZLD. An effluent treatment plant (ETP) treats wastewater to the limits in your consent, typically BOD 30 mg/L or less and COD 250 mg/L or less, and then discharges it. A zero liquid discharge (ZLD) plant recovers 95–99% of the water and leaves only dry salt. Your Consent to Operate decides which applies.
This guide compares the two and sets out how to decide. For the regulatory background, see our guide to the CPCB ZLD mandate; for costs by capacity, see our ETP and ZLD cost guides.
What is the difference between an ETP and a ZLD plant?
An ETP is a treatment plant; ZLD is an outcome. An ETP removes BOD, COD and suspended solids so effluent can be discharged within limits. A ZLD plant adds reverse osmosis and thermal evaporation behind the ETP so that nothing is discharged: 95–99% of the water returns to the process and the remainder leaves as dry salt.
A conventional ETP has three steps. Primary physico-chemical treatment removes 60–80% of suspended solids and 30–40% of BOD. Biological treatment (MBBR, SBR or extended aeration) removes most of the remaining organic load, and tertiary filtration, activated carbon or advanced oxidation polishes the outlet.
What an ETP does not remove is dissolved salt, so treated effluent can meet its BOD and COD limits and still carry high TDS. ZLD deals with that. Reverse osmosis recovers typically 70–80% of the feed as clean permeate, and a Multiple Effect Evaporator (MEE) and Agitated Thin Film Dryer (ATFD) evaporate the reject to dry solids, recovering the condensate too.
Is ZLD mandatory for my industry?
ZLD is mandatory only where CPCB directions, State Pollution Control Board orders or your own Consent to Operate require zero discharge. In practice that covers textile dyeing, printing and bleaching units in notified clusters, red-category pharmaceuticals, tanneries, dye manufacturers and distilleries. Most other units need an ETP meeting discharge standards such as BOD 30 mg/L or less.
Textile clusters such as Tirupur, Surat, Panipat and Ludhiana are the best-known examples, but sector lists are only a guide. The operative document is your Consent to Operate, and State Pollution Control Boards can set conditions stricter than the CPCB general standards. If your consent specifies zero discharge, that is the standard you will be inspected against, whatever your sector.
Under such a condition any outfall counts as discharge, including RO reject sent to a drain. Read your consent before you buy anything, and again when applying for a Consent to Establish for an expansion.
How do an ETP and a ZLD plant compare side by side?
The biggest practical differences are water recovery and energy. An ETP discharges its treated water, or reuses part of it in cooling towers or landscaping, and uses around 0.4–1.2 kWh per m³. A ZLD plant recovers 95–99% of the water but uses 8–18 kWh per m³, because evaporation is energy-intensive.
| Factor | ETP | ZLD plant |
|---|---|---|
| Purpose | Treat effluent to discharge standards | Eliminate liquid discharge entirely |
| Outlet | Treated effluent to drain, sewer or reuse (BOD 30 mg/L or less, COD 250 mg/L or less) | No liquid outlet; recovered water and dry salt |
| Water recovery | Partial, only where a reuse stage is added | 95–99% |
| Typical stages | Primary physico-chemical, biological (MBBR/SBR/ASP), tertiary polishing | ETP + RO concentration + MEE + ATFD, optionally a crystalliser |
| Residue | Dewatered sludge at 20–30% dry solids | Sludge plus dry salt; salt of 98% purity or more can sometimes be resold |
| Footprint | Compact, especially MBBR or SBR designs | Roughly 800–1,200 m² for a 500 KLD plant |
| Energy | About 0.4–1.2 kWh per m³ | About 8–18 kWh per m³ |
| Build time | 60–120 days | 5–6 months for a standard 500 KLD plant |
| When required | Almost any unit generating process effluent | Where CPCB directions, SPCB orders or the consent require zero discharge |
These are Navbharat Water design ranges; actual figures depend on inlet quality and flow variation.
How do ETP and ZLD costs compare?
Indicatively, a 200–500 KLD ETP with RO polishing costs ₹1.2–3.5 Cr, while a complete 500 KLD ZLD plant (ETP + RO + MEE + ATFD) costs ₹3.5–5.5 Cr and ₹80–120 per KL treated to run. Most of the gap comes from the evaporation stage and the energy it consumes.
At the smaller end, a 20–50 KLD packaged MBBR ETP typically costs ₹15–30 lakh. Across all sizes, ZLD systems range from about ₹50 lakh to ₹25 Cr. These figures are indicative: inlet TDS and COD, the recovery target, steam source and salt disposal all move the price, and a firm quote needs effluent characterisation and a water and salt mass balance.
ZLD also returns value: for a 1 MLD plant, average freshwater savings are ₹2–5 Cr a year. Where capital is the constraint, BOOT replaces it with a per-kilolitre fee (see the FAQs below).
Can an existing ETP be upgraded to ZLD?
Usually, yes. If the existing ETP reliably delivers RO-feed quality, typically TSS below 50 mg/L and COD below 500 mg/L, RO concentration and an evaporation stage can be added as a bolt-on. A retrofit of this kind typically costs 30–40% less than building a greenfield ZLD plant.
The condition matters. Batch processes produce peaks in flow, colour and COD, and an ETP sized for average flow rather than a 1.5–2 times peak will foul the RO membranes downstream. Audit the ETP across a full production cycle, build a water and salt mass balance, and confirm space and steam availability before committing.
If you are buying an ETP now in a sector where zero discharge conditions are common, ask for a ZLD-ready layout, with space reserved for RO and evaporation and a tertiary stage designed to RO-feed quality.
How long does each option take to build?
A standard ETP takes 60–120 days from design approval to commissioning, and modular systems can be ready in about 45 days. A standard 500 KLD ZLD plant takes 5–6 months from order to operational compliance, and consent processing of 8–12 weeks should run in parallel with the engineering.
For ZLD, the 5–6 months break down into 4–6 weeks of design, 10–14 weeks of fabrication, 6–8 weeks of civil work running in parallel, and 2–3 weeks of commissioning. If a notice is already on the table, Navbharat Water can mobilise for a site assessment within 48 hours and provide an interim solution while the permanent plant is built.
Which should my factory choose?
Choose ZLD if your consent, cluster or sector requires zero discharge, or if water is scarce and costly enough that recovering 95–99% of it pays back. Otherwise, a well-designed ETP meeting BOD 30 mg/L or less and COD 250 mg/L or less is the right investment, ideally laid out so ZLD can be added later.
Work through these questions in order:
- Does your Consent to Operate specify zero discharge? If so, the decision is made.
- Is your unit in a notified cluster or a sector where zero discharge is common? Plan for ZLD even if your consent does not yet require it.
- Is your effluent high in TDS and needed for reuse? That points towards RO and, eventually, ZLD.
- What does freshwater cost you? High water costs shorten the payback on recovery.
- Is capital the constraint? BOOT converts it into a per-kilolitre fee from 50 KLD upwards.
- Is your flow below 50 KLD? Shared cluster infrastructure or a rental model is usually better value than standalone ZLD.
Navbharat Water has commissioned more than 150 treatment plants and builds ZLD plants from 10 KLD to 10 MLD for feed TDS of 2,000–80,000 mg/L. To scope either option, see Navbharat Water's Effluent Treatment Plant solutions or its Zero Liquid Discharge systems.
Frequently asked questions
Does every factory in India need an ETP?
Most factories that generate industrial process wastewater do. Effluent must meet the standards in the unit's Consent to Operate before it leaves the site, and an ETP is the usual way to achieve that. Units that generate only domestic sewage need a sewage treatment plant instead. Many factories need both, and the two can be designed and commissioned as a single integrated plant.
Does ZLD mean 100% water recovery?
No. Zero liquid discharge means no liquid leaves the site, not that every litre is recovered. In practice ZLD plants recover 95–99% of incoming effluent as reusable water. The remainder leaves as dry salt from the ATFD or crystalliser. Salt of 98% purity or more can sometimes be sold as sodium sulphate or sodium chloride; mixed salt typically goes to landfill.
Can RO reject go to a drain or an open pond under a ZLD condition?
No. Under a zero discharge condition, any outfall counts as discharge, including RO reject sent to a drain. Reject stored in open ponds is also a risk, because ponds can overflow in the monsoon. A compliant ZLD plant evaporates the RO reject in an MEE and ATFD so that only dry solids leave the site, with the condensate recovered for reuse.
How much more energy does ZLD use than an ETP?
Considerably more. Navbharat Water ETPs typically use 0.4–1.2 kWh per m³, while its ZLD plants draw 8–18 kWh per m³, highest for MEE-based trains and lowest for RO-dominated configurations. Maximising RO recovery before the evaporator is the main lever, and plants with waste steam available typically have 30–40% lower operating costs.
Can I get a ZLD plant without paying the capital cost upfront?
Yes, for most plant sizes. Under a BOOT contract, Navbharat Water finances, builds and operates the plant on your site and you pay a fee per kilolitre treated. Terms run 10–20 years, typically 12–15, and BOOT is viable from 50 KLD upwards. Below 50 KLD, shared cluster ZLD or a rental model with a per-kilolitre fee is usually more practical.
